Building low power applications on Espressif chips: Ultra-Low-Power (ULP) coprocessor

In this article, we’ll start with a quick overview of Ultra Low Power coprocessors (ULPs) in Espressif chips and how they can significantly reduce power consumption in your applications. Then, we’ll walk through a tutorial on how to use ULPs in practice!

Imagine this scenario: you have finished programming your application, designed your PCB with a battery circuit, and you are finally ready to set it free by disconnecting the umbilical cord — the USB cable. But to your great disappointment, you find too soon that your small LiPo battery drains in a matter of hours.

If you plan to run your application on a battery, it is of utmost importance to know how to design your hardware and software so that the application does not gobble up the power like a vacuum cleaner. Even something as simple as polling a GPIO can have a drastic impact on power consumption. Doing it the easiest way vs. using the chip’s low-power features can result in an average difference of 22 mA vs. 22 µA. In other words, with your 350 mAh LiPo battery, it is the difference between it lasting 16 hours vs. 2 years.

In this article, we’ll introduce one of the features that Espressif chips provide to achieve low-power consumption: the Ultra-Low-Power coprocessor (ULP), a processor separate from the main CPU. In a nutshell, if we run parts of our application on the ULP while the rest of the system sleeps, we can achieve much lower power consumption.

This article will focus on the latest iteration of the ULP — the LP-Core — available on the ESP32-C6 and a range of other new chips. For building the application, we will use ESP-IDF v5.4.

Low-power on Espressif chips
#

Reducing power consumption of an application running on a microcontroller is mainly achieved through two general methods:

Clock gating and/or power gating parts of the chip, effectively turning off parts of the chip that you don’t need.
Frequency scaling, reducing the clock frequency of the chip to lower power consumption.

All Espressif chips support both methods but with varying degrees of flexibility. Newer chips, such as the ESP32-C6, have an even more powerful Power Management Unit (PMU), allowing for much finer control over which parts of the chip can be clock-gated or powered down.

In ESP-IDF, these two power-saving methods are exposed to users through sleep modes and power management:

Sleep modes: Allows for powering down parts of the chip, mainly through two different modes:
- Deep Sleep: Everything except a few low-power peripherals (e.g., the LP timer responsible for waking up the chip) is powered down and the state is lost. After waking up, the chip will boot up and configure the system again, similar to a power-on reset.
- Light Sleep: Most peripherals are powered down, but memory remains powered on, allowing the system to keep its state and continue executing from where it left off.
Power Management: A high-level power management interface for the main high-performance CPU that can handle both automatic frequency scaling and entering light sleep when the chip is idle.

What the ULP brings to the table in a low-power context is the ability to run even while the system is in deep sleep. This allows us to execute code and perform simple operations while keeping most of the system powered down.

ULP
#

The ULP is a coprocessor that operates independently from the main CPU. Its main advantage is that it is powered and clocked by a power domain controlled seperately from the rest of the system. This allows it to continue operating even while the rest of the system is in deep sleep. For more information about power domains on the ESP32-C6, see the ESP32-C6 TRM → Low-Power Management.

This enables us to offload certain tasks to the ULP, such as sensor readings, while waking up the main CPU only when it is necessary for some more complex task.

Imagine this scenario: you’re designing a smart plant-watering IoT device that measures soil humidity and waters the plant when needed. For a simple task like this, you could use the ULP to further reduce power consumption. While the rest of the system is powered down and sleeping, the ULP can periodically wake up, take measurements, as well as trigger watering action if necessary. Only when it is strictly necessary will the ULP wake up the main CPU and the rest of the system to perform actions that it cannot do — for example, to update the cloud with the latest device status over Wi-Fi.

To summarize what the ULP is suitable for:

✅ Save power by performing simple tasks while the rest of the system sleeps
❌ Help you achieve lower power-consumption during Wi-Fi or Bluetooth connections
✅ Assist main CPU by offloading simpler tasks

Three generations of ULP coprocessor
#

As Espressif chips have evolved, so has the ULP. This article mainly focuses on the latest iteration of the ULP at the time of writing — the ESP32-C6’s LP-Core. Some of the older chips had previous iterations. All in all, the ULP iterations are as follows:

ULP-FSM (ESP32, ESP32-S2, ESP32-S3) – a simple state machine
- Programmed using an assembly-like language
- Able to perform simple tasks
- Can access a limited part of the chip’s memory, the low power memory.
ULP-RISC-V (ESP32-S2, ESP32-S3) – a RISC-V based CPU
- Programmed using standard C
- More powerful and much more approachable than the ULP-FSM
LP-Core (ESP32-C6, ESP32-C5, ESP32-P4): – even more powerful RISC-V based CPU
- Programmed using standard C
- Has an interrupt controller that conforms to the RISC-V standard
- Now able to access all of the chip’s memory and peripherals when the whole system is powered on;
- Has additional low-power peripherals, including UART, SPI and JTAG debugging

As we focus on the ESP32-C6’s ULP LP-Core in this article, let’s review its specifications:

32-bit RISC-V IMAC (Integer, Multiplication, Atomic, Compressed Instructions) CPU
20 MHz clock frequency
Access to 16 KB of low-power memory (LP-RAM), memory which can stay powered on during sleep
Access to low-power peripherals: LP IO, LP-I2C, LP-UART, and LP timer while the system is in deep sleep
Access to all of the chip’s memory and peripherals when the whole system is in active mode. Enabling using the LP-Core as a generic co-processor instead of only as a low-power feature.
JTAG debugging interface

How to use the LP-Core
#

Now we know what the LP-Core is, its features, and what it can and cannot do. But how do we go about using it? How do we compile and load an application for it?

The standard way of using the LP-Core is to compile a separate application for it. This means that writing code for the LP-Core follows a slightly different workflow compared to your regular IDF apps. Luckily, ESP-IDF already integrates building LP-Core apps into its build system and provides APIs to load, run, and interact with the LP-Core to simplify this process for you!

In the following section, we will try this workflow and create your first ULP app. To understand how to structure and build a ULP app, we will:

Create an empty app that does nothing and build it.
Learn how to use the APIs provided by ESP-IDF to load and run the ULP app.
See how our main CPU application can interact with the ULP application and exchange information.
Put the main system into deep sleep and show how the ULP can wake up the main CPU.

Building your LP-Core app
#

All the following code and API are based on ESP-IDF v5.4.

The files and code required for this step should look like this.

Our main/ directory contains a folder for our LP-Core app. It is called ulp_app/ in this case.

To be able to build an LP-Core app, we also need some scaffolding files:

Every C application needs an entry point: the empty main() function in ulp_app/ulp_main.c is the entry point for our LP-Core app.

In the project’s main CMakeLists.txt, we’ve added the CMake functions needed to build the LP-Core app:

idf_component_register(SRCS "my_ulp_app.c"
                    INCLUDE_DIRS "."
                    PRIV_REQUIRES ulp)

# LP-Core support additions to component CMakeLists.txt.
set(ulp_app_name "ulp_hello_world")

# Specify all C and Assembly source files.
set(ulp_sources "ulp_app/ulp_main.c")

# List all the component source files which include automatically generated LP-Core export file, ${ulp_app_name}.h:
set(ulp_exp_dep_srcs "my_ulp_app.c")

# Call function to build LP-Core binary and embed in project using the argument provided above
ulp_embed_binary(${ulp_app_name} "${ulp_sources}" "${ulp_exp_dep_srcs}")

With these scaffolding in place, we can set up the target with idf.py set-target esp32c6 and configure the necessary LP-Core related configs in menuconfig:

To enable building and using the LP-Core, CONFIG_ULP_COPROC_ENABLED
To configure the amount of LP memory to reserve for the LP-Core app, set CONFIG_ULP_COPROC_RESERVE_MEM. For our small application in this article the default value is sufficient, but when creating more complex apps this value might have to be increased.

Now you should have everything necessary to build our LP-Core app. Building it can be done the same way you normally build your IDF projects, e.g., with:

idf.py build

If the build was successful, you should now have an LP-Core app built as a separate binary in:

build/esp-idf/main/ulp_hello_world

It is already possible to flash the application now, but the LP-Core would not run our main function as we still need to initialize and run the LP-Core.

Running your LP-Core app
#

Now that we have built the LP-Core binary, let’s take a look at how to run it. The state of the project for this step will look like this.

In my_ulp_app.c’s main function we have added the following changes:

#include "ulp_lp_core.h"

extern const uint8_t ulp_hello_world_bin_start[] asm("_binary_ulp_hello_world_bin_start");
extern const uint8_t ulp_hello_world_bin_end[]   asm("_binary_ulp_hello_world_bin_end");

void app_main(void)
{
    ulp_lp_core_cfg_t cfg = {
        .wakeup_source = ULP_LP_CORE_WAKEUP_SOURCE_LP_TIMER,
        .lp_timer_sleep_duration_us = 1000000,
    };

    ESP_ERROR_CHECK(ulp_lp_core_load_binary(ulp_hello_world_bin_start, (ulp_hello_world_bin_end - ulp_hello_world_bin_start)));
    ESP_ERROR_CHECK(ulp_lp_core_run(&cfg));

    printf("LP core loaded with firmware and running successfully\n");
}

To explain a bit more what is happening:

extern const uint8_t ulp_hello_world_bin_start[] and .._end[] import the addresses to where the LP-Core binary is placed in flash. The LP-Core binary was automatically included into the app binary when we built our app.

ulp_lp_core_load_binary() copies the LP-Core binary from flash into LP-RAM, which is the memory area we have reserved for the LP-Core.

ulp_lp_core_run() then finally configures the LP-Core according to our config parameters. The wakeup_source is what will trigger the LP-Core to start running, in this case we choose the LP timer, which will make the LP-Core app be re-ran periodically. This is a common use-case when we want to monitor something with the LP-Core, but we don’t want it to be active all the time in order to further reduce power consumption. For more information about other wake-up sources, see ulp-lp-core-program-flow.

The LP-Core now has everything it needs to run, if you selected a wake-up source which has an immediate effect (e.g. ULP_LP_CORE_WAKEUP_SOURCE_HP_CPU) then the LP-Core will already be running. In our example we choose the LP_Timer with a sleep duration of 1 second, so the first run of the LP-Core app will occur one second after calling ulp_lp_core_run().

Interacting with the LP-Core
#

We now have an app running on the LP-Core, but since the app is just an empty main(), it doesn’t do anything and we haven’t seen any proof that it is actually running.

If you want to see how the code look like at this stage you can find it here. Let’s expand our LP-Core app to increment a variable every time it runs.

In ulp_app/ulp_main.c, we have updated with a counter variable that will be incremented for every run:

int my_counter = 0;

int main (void)
{
    my_counter++;
}

Note that an LP-Core app’s data and bss sections, i.e. global and static variables, are only initialized when you do ulp_lp_core_load_binary(), so here my_counter will keep its value between every call to main(). The life-cycle of an LP-Core app is a bit different from your regular apps. A typical LP-Core app will boot up, perform some measurements or actions, before returning from main() and shutting down, waiting for the next wake-up to restart it.

Even though letting the LP-Core shut itself down is optimal from a power consumption point of view, it is of course also possible for users to never return from main(), keeping the LP-Core running indefinitely.

Observing the result
#

Now we will keep incrementing my_counter once every 1 second (the wake-up interval we configured), but how do we monitor the results? The HP CPU is also able to access the LP memory the LP-Core runs from, so it is just a matter of getting the address of the variable. To simplify this ESP-IDF will automatically generate a header file, ulp_app_name.h which exports all of the global symbols in the LP-Core app.

In my_ulp_app.c, we’ve added some code to continuously print the value of the counter to the console.

while(1) {
    printf("ulp counter: %lu\n", ulp_my_counter);
    vTaskDelay(300 / portTICK_PERIOD_MS);
}

We have also included the autogenerated ulp_hello_world.h to gain access to the exported variable from the LP-Core app.

#include "ulp_hello_world.h"

Rebuild and flash your software and voila:

We finally have the proof that the LP-Core is running independently and doing what we expect it to do!

Putting the system to sleep
#

We’ve been talking about how to reduce power consumption, but until now all we have done is just add one more module, the LP-Core, which runs in parallel with everything else on the chip, consuming even more power!

The last missing part of the puzzle is putting the rest of the system to sleep while the LP-Core works. Most applications will eventually want to wake up the main processor to perform tasks which the LP-Core isn’t suited for, so we’ll also add the LP-Core as a wake-up source for the HP-CPU.

The final version of our application will now be this.

In my_ulp_app.c, we have replaced the printing of the counter variable with code to put the system into deep sleep:

/* Enable the LP-Core to wakeup the rest of the system */
ESP_ERROR_CHECK(esp_sleep_enable_ulp_wakeup());

// Go into to deep sleep
esp_deep_sleep_start()

We have also added a check and a print for the case when the wake-up is caused by the LP-Core as the first action after entering main():

if (esp_sleep_get_wakeup_cause() == ESP_SLEEP_WAKEUP_ULP) {
    printf("Wake-up cause was: ESP_SLEEP_WAKEUP_ULP\n");
}

And as a final step, we’ve modified our LP-Core code in ulp_app/ulp_main.c to include waking up the HP-CPU:

if (my_counter >= 5) {
    ulp_lp_core_wakeup_main_processor();
}

Since we configured the LP timer to wake up the LP-Core with a period of 1 sec, then this condition means that we will wake up the main processor on the 5th iteration, i.e., after 5 seconds.

If you now rebuild and re-flash your project, you’ll see that the HP-CPU resets once every 5 second with the reset reason rst:0x5 (SLEEP_WAKEUP).

Measuring power consumption
#

By connecting any device that can measure power consumption, we can get a better idea of what is happening when our code is running.

We can see two spikes in the measured power consumption, separated by approximately 5 seconds of low power consumption. These two spikes are when the HP-CPU is active, as expected our LP-Core application wakes it up every 5 seconds.

Zooming in on one of the high-activity sections, we can see the power consumption for the ESP32-C6 when booting up, running the ROM bootloader, followed by the secondary bootloader before finally booting our application and going into deep sleep. Without any optimization for start-up time, the whole process takes about 200 ms. Optimizing for start-up time is often important in low-power applications as any time spent booting is time not spent sleeping. For more information on how to do this, see:

If we look at the period of low power consumption when the HP-CPU is sleeping we see the following:

There are spikes of activity every one second, which is the wake-up interval for our LP-Core. During these short wake-ups the whole system is consuming approximately 20 µA. Between the wake-ups, both the LP-Core itself, HP-CPU, and almost all of the system is powered down, and we achieve the lowest possible power consumption: 10 µA.
