Lightweight MQTT Broker for ESP32: Mosquitto ported to ESP-IDF

Table of Contents

Mosquitto – the industry-standard MQTT broker – has been ported to ESP-IDF. Its lightweight version retains Mosquitto’s core functionality and security features to run on resource-constrained IoT devices. This MQTT broker is ideal for edge computing, testing, and standalone IoT deployments. In this article, we will do an overview and show you how to get started.

Introduction
#

Traditionally, MQTT brokers run in the cloud or on powerful servers. But what if we could run them directly on IoT devices?

The lightweight implementation of the popular Eclipse Mosquitto™ broker makes this possible. Ported to ESP-IDF, this version brings MQTT broker functionality to edge devices and reduces the need for always-on external infrastructure.

Optimized for the limited resources of the ESP32, this port maintains the core features of Eclipse Mosquitto and benefits from its feature completeness, configurability, extensibility, and portability. Running this MQTT broker directly on the device reduces latency, enhances privacy by keeping data local, and allows for fully autonomous IoT networks – even in the absence of internet connectivity.

Key features
#

Supports TLS transport (based on ESP-TLS)
Supports plain TCP transport
Single listener configuration (only one transport at a time)

Use cases of running an MQTT broker on IoT devices
#

While it is possible to run an MQTT broker on IoT devices, what are the use cases and considerations? Let’s explore three interesting scenarios where running the broker on an IoT device is particularly beneficial.

Local broker for private IoT networks
#

One powerful use case is running a local Mosquitto broker on the ESP32 to serve local IoT devices within a private network segment:

Create an independent home automation hub that works even when internet connectivity fails
Integrate with platforms like ESP-Home, Home Assistant, or custom IoT devices
Enhance privacy by keeping all data within the local network

Testing on target
#

Another use-case is testing MQTT applications directly on the ESP32. By running both the client and broker on the same chip, developers can:

Develop and test MQTT-based applications without external dependencies
Simulate complex MQTT interactions in a controlled environment
Debug communication issues in isolation before deploying to a production environment
Create self-contained test fixtures for IoT product validation

Bridged brokers over P2P networks
#

The serverless MQTT example demonstrates how two ESP32 devices running Mosquitto can create a synchronized broker system over peer-to-peer connections:

Connect IoT devices across separate private networks without requiring cloud infrastructure
Synchronize two local MQTT networks across the internet using secure peer-to-peer connections
Create resilient IoT networks that can operate across geographical locations
Enable MQTT communication between networks separated by NATs or firewalls

Technical specifications
#

Memory Footprint:
- Program memory: ~60 kB
- Stack size: Minimum 5 kB (recommended)
- Heap usage: ~2 kB on startup, ~4 kB per connected client
Connectivity: TCP or TLS transport
API: Simple C API with broker configuration structure
Dependencies:
- ESP-IDF components: newlib, esp_timer, esp_tls (for secure TLS connections)
- Managed components: sock_utils (for porting)

Implementation details
#

The MQTT broker is implemented as a port of the original Mosquitto codebase. It follows a single-threaded, event-driven architecture that efficiently handles multiple connections through socket multiplexing. The core of this implementation consists of a number of key components covered below.

Socket multiplexing
#

The broker uses an abstracted multiplexing layer that utilizes polling implementations with:

Mux Layer: An abstraction layer (mux.c) that provides common interface functions for socket multiplexing
Poll Implementation: Uses standard poll() mechanisms for handling multiple file descriptors

Event loop
#

The main broker loop (loop.c) performs the following operations:

Processes incoming client connections
Handles socket read/write events
Manages client keepalive tracking
Processes message queues and subscriptions
Handles disconnections and cleanup

ESP-IDF integration
#

The port includes a custom implementation (net__esp_tls.c) that integrates ESP-TLS for secure connections, which handles TLS context initialization and manages secure socket connections. ESP-TLS is an internal component of ESP-IDF providing simplified and abstracted access to security related APIs, you can read more about it in the official ESP-IDF documentation.

Simplified message handling
#

graph TD
    A[Client Connection Request] --> B[Socket Accept]
    B --> C{TLS Enabled?}
    C -->|Yes| D[ESP-TLS Context Creation]
    C -->|No| E[Plain TCP Connection]
    D --> F[TLS Handshake]
    F --> G[Connection Ready]
    E --> G
    G --> H[Socket Multiplexing]

    subgraph "Event Loop"
        H --> I[Poll for Events]
        I --> J[Process Socket Events]
        J --> K[Handle Client Messages]
        K --> L[Route Messages to Subscribers]
        L --> I
    end

    M[Client Disconnect] --> N[Socket Cleanup]
    N --> O[Release Resources]

How to use the MQTT broker in your project
#

To use the ESP32 Mosquitto Port in your projects, you’ll need to download the mosquitto component and initialize the broker with appropriate configuration settings. It is important to provide sufficient stack space for the running task.

Start from an existing example
#

Use the below command to create a new project from the simple broker example

$ idf.py create-project-from-example "espressif/mosquitto:broker"

Configure the project with:

$ idf.py menuconfig

In the appeared configuration menu:

Go to Connection and choose the preferred connection
Go to Example and choose the example transport (TLS or plain TCP) Then build and flash normally with:

$ idf.py build flash monitor

Use the broker in your project
#

Add mosquitto component to your project dependency with:

$ idf.py add-dependency "espressif/mosquitto"

Configure the broker and start it in your application:

struct mosq_broker_config config = {
    .host = "0.0.0.0",  // Listen on all interfaces
    .port = 1883,       // Standard MQTT port
    .tls_cfg = NULL     // No TLS in this example
};

// Start the broker (runs in the current task)
mosq_broker_run(&config);

Future development
#

The ESP32 Mosquitto Port is designed to be expanded with additional features in future releases, supporting:

Plugins and configuration files to extend broker functionality
WebSocket and Websocket Secure transports

License information
#

The ESP32 Mosquitto Port is licensed under the dual Eclipse Distribution License (EDL) and Eclipse Public License (EPL). These licenses ensure that the software remains free and open-source while providing clear terms for usage, modification, and distribution.

Eclipse Distribution License (EDL): A BSD-style license that allows for commercial use, modification, distribution, and private use with minimal restrictions.
Eclipse Public License (EPL): A copyleft license that requires any distributed modifications to also be licensed under the EPL.

For full license details, please refer to the LICENSE files included in the source code repository:
