Introducing the SPIFFS component

Introduction

#

Storing files on flash—configuration, web assets, or firmware data—is common in embedded applications. Based on the original SPIFFS project, the SPIFFS component in ESP-IDF provides a lightweight filesystem for SPI NOR flash: it supports wear levelling, consistency checks, and integrates with the rest of ESP-IDF so you can use familiar C and POSIX file APIs.

This article introduces the SPIFFS component, how it collaborates with the VFS (Virtual File System) component and with tools like SPIFFSgen, and points you to a working example.

SPIFFS comes bundled with ESP-IDF rather than being distributed via the Component Registry. You use it by mounting a SPIFFS partition through VFS, then reading and writing files via fopen, fprintf, fread, and similar functions.

Key Features

#

The SPIFFS component offers:

• Standard file I/O API: Use familiar C and POSIX calls—fopen, fread, fwrite, fprintf, stat, unlink, rename, and the like—so you can read and write SPIFFS files without any filesystem-specific API. This is provided via the VFS layer once SPIFFS is mounted.
• Partition-based: You define a SPIFFS partition in your partition table; the component uses that partition for all file data.
• Wear levelling: Helps extend flash lifetime by spreading writes across the partition.
• File system consistency checks: You can run an explicit integrity check (and repair) via the esp_spiffs_check() function; see Discussion: integrity check below.
• Format-on-mount option: format_if_mount_failed lets you automatically format the partition if mount fails (e.g. first boot or after erase).

Application use cases

#

SPIFFS is often used for:

• Web server assets: HTML, CSS, JavaScript for an ESP32 web server
• Configuration and calibration: Device config or calibration data in files, updated without reflashing the whole app
• Scripts and data: Lua scripts, JSON config, or small datasets read at runtime
• OTA and assets: Firmware metadata or asset packs updated separately from the main app

Basic example: mount, write, and read

#

The storage/spiffs example in ESP-IDF shows the minimal flow: register SPIFFS with VFS, write a file, rename it, then read it back. No special hardware is required; any board with a SPIFFS partition in the partition table will work.

What the example does

#

1. Prepares a compile-time partition layout that includes a SPIFFS partition labeled storage.
2. Calls esp_vfs_spiffs_register() to initialize SPIFFS, mount it, and register it with VFS at a path prefix (e.g. /spiffs).
3. Creates a file with fopen and writes a line with fprintf.
4. Renames the file (after checking for an existing destination with stat and removing it with unlink if needed).
5. Opens the renamed file, reads the line back with fgets, and prints it to the console.
6. Unregisters SPIFFS with esp_vfs_spiffs_unregister().

Partition size and label are defined in partitions_example.csv in the example. You can run it with idf.py -p PORT flash monitor. To erase the SPIFFS partition and start fresh, run idf.py erase-flash before flashing again.

Prerequisites

#

• A project with a partition table that includes a SPIFFS partition (see the example’s partitions_example.csv).
• No special hardware; the example runs on any supported target (ESP32, ESP32-C3, etc.).

Step 1: Prepare partition table at compile time

#

Before mounting SPIFFS in code, make sure your build uses a partition table that contains a SPIFFS partition with the label used by your code (here: storage).

In idf.py menuconfig:

• Go to Partition Table.
• Set Partition Table to Custom partition table CSV.
• Set Custom partition CSV file to your file (for example, partitions_example.csv).

The ESP-IDF example uses the following partitions_example.csv:

# Name, Type, SubType, Offset, Size, Flags
# Note: if you have increased the bootloader size, make sure to update the offsets to avoid overlap
nvs, data, nvs, 0x9000, 0x6000,
phy_init, data, phy, 0xf000, 0x1000,
factory, app, factory, 0x10000, 1M,
storage, data, spiffs, , 0xF0000,

The key line for SPIFFS is:

storage, data, spiffs, , 0xF0000,

At build time, ESP-IDF compiles this CSV into the partition table binary and flashes it with your app.

Step 2: Include and configure

#

Include the SPIFFS/VFS header and set the partition label and mount path:

#include "esp_vfs_spiffs.h"

static const char *TAG = "example";

#define PARTITION_LABEL  "storage"
#define BASE_PATH        "/spiffs"

Step 3: Register SPIFFS with VFS

#

In app_main() (or after NVS/other init), fill the configuration and register:

esp_vfs_spiffs_conf_t conf = {
    .base_path = BASE_PATH,
    .partition_label = PARTITION_LABEL,
    .max_files = 5,
    .format_if_mount_failed = true
};

esp_err_t ret = esp_vfs_spiffs_register(&conf);
if (ret != ESP_OK) {
    ESP_LOGE(TAG, "Failed to initialize SPIFFS (%s)", esp_err_to_name(ret));
    return;
}

Setting format_if_mount_failed to true formats the partition on first use or when mount fails, which is convenient for development.

Step 4: Use standard file APIs

#

Once mounted, use C library functions with paths under BASE_PATH:

FILE *f = fopen("/spiffs/hello.txt", "w");
if (f != NULL) {
    fprintf(f, "Hello World!\n");
    fclose(f);
}

// Later: open for read, rename with stat/unlink as needed, etc.

All of this goes through VFS to the SPIFFS driver; no SPIFFS-specific read/write calls are needed.

Step 5: Unregister when done

#

Before shutting down or if you need to remount:

esp_vfs_spiffs_unregister(PARTITION_LABEL);

The example also demonstrates getting partition info with esp_spiffs_info() and, optionally, running an integrity check with esp_spiffs_check() — we discuss that option and alternatives in Integrity check.

Complete source code

#

The full example is in the ESP-IDF repository:

• esp-idf/examples/storage/spiffs

For embedding files with SPIFFSgen in the build (an alternative to creating files only at runtime):

• esp-idf/examples/storage/spiffsgen

Discussion: options in the example and alternatives

#

The example above uses a small set of SPIFFS and VFS options. This section walks through those choices and the alternatives the component offers so you can adapt them to your project.

Registration, base_path, and partition_label

#

The example registers SPIFFS with base_path = "/spiffs" and partition_label = "storage". Those two values answer different questions: where the file data lives on flash, and how your application refers to it by path.

partition_label — “Which region of flash?” (esp_partition)

#

Your partition table divides flash into named regions. Each region has a label (e.g. storage or spiffs). When you set partition_label to "storage", the SPIFFS component uses the esp_partition API under the hood: it looks up the partition by that label and gets the offset and size of that region in flash. SPIFFS then uses that region exclusively for all file data. So partition_label is the link between your config and the physical flash layout. If you have two SPIFFS partitions (e.g. storage and assets), register each with its own label; each gets its own region of flash.

As an alternative, you can pass partition_label = NULL to use the first SPIFFS partition in the table (the example’s code can use NULL; the snippet above uses "storage" for clarity). Useful when you have only one SPIFFS partition and don’t care about the name.

base_path — “How do I name files in code?” (VFS)

#

The base_path (e.g. /spiffs) is the mount point in the VFS layer. VFS routes path-based calls to the driver that registered with that prefix. When you call fopen("/spiffs/hello.txt", "r"), VFS hands the request to the SPIFFS driver registered with base_path = "/spiffs"; the driver sees the relative part (hello.txt) and uses the partition it already knows from partition_label. So base_path is a naming convention: the “directory” under which all files for this SPIFFS instance appear. It doesn’t change where data is stored.

As an alternative, you can set base_path to any path that doesn’t clash with another mount point (e.g. /data, /assets). The example uses /spiffs by convention.

How they work together: partition_label selects which flash partition holds the data (via esp_partition); base_path selects which path prefix in VFS points to that data. Both are needed at registration so VFS can route requests and the driver can use the right partition.

format_if_mount_failed and max_files

#

The example sets format_if_mount_failed = true and max_files = 5.

• format_if_mount_failed: If mount fails (e.g. unformatted or corrupted partition), the component will format the partition and try again. Convenient for development and first boot; you can set it to false in production if you prefer to handle mount failure yourself (e.g. call esp_spiffs_format() or esp_spiffs_check() and retry).
• max_files: Maximum number of files open at the same time. The example uses 5; increase this if your application opens more files concurrently.

The esp_vfs_spiffs_conf_t struct has no other fields—only base_path, partition_label, max_files, and format_if_mount_failed.

Integrity check

#

SPIFFS can be corrupted if power is lost during a write. The component does not run an automatic integrity check at mount time; it exposes a function you call when you need it.

What the example does: The storage/spiffs example can run esp_spiffs_check(partition_label) in two situations:

1. Optional check on start: The example’s menuconfig (“SPIFFS Example” menu) has Perform SPIFFS consistency check on start (CONFIG_EXAMPLE_SPIFFS_CHECK_ON_START). When enabled, the example calls esp_spiffs_check(conf.partition_label) once after a successful mount, before any file I/O.
2. Recovery when info is inconsistent: If esp_spiffs_info() reports used > total, the example calls esp_spiffs_check() as a recovery path (independent of the menuconfig option).

esp_spiffs_check(partition_label) This function must be called manually on an already mounted partition. It scans the filesystem to repair corrupted files and clean up unreferenced pages (for example, after a power loss), returning ESP_OK, ESP_ERR_INVALID_STATE (if not mounted), or ESP_FAIL. Note that this check is expensive, requiring multiple full scans—on large partitions, it can introduce noticeable delays. Unlike some filesystems, esp_vfs_spiffs_conf_t does not include an automatic “check on mount” flag; you control when the check runs.

Alternatives: In your own project you can: call esp_spiffs_check() after mount only when you want a boot-time check (like the example option); call it only when you detect a problem (e.g. used > total or after detected power loss); or run it as periodic maintenance. Trade-off: better recovery vs. longer, blocking boot on large partitions. The SPIFFS FAQ has more detail on when to run the check.

Populating the partition: SPIFFSgen

#

The example creates files only at runtime (e.g. with fprintf). To embed host files (HTML, config, assets) into the SPIFFS partition and flash them with the app, the recommended tool is SPIFFSgen (spiffsgen.py).

spiffsgen.py is a write-only Python tool that builds a SPIFFS image from a host directory. It is part of the spiffs component and you can use it standalone or via the build system.

Standalone:

python spiffsgen.py <image_size> <base_dir> <output_file>

The image can be flashed with esptool or parttool.py. Run python spiffsgen.py --help for optional arguments (page size, block size, etc.).

Build system:

Invoke it from CMake so the image is built (and optionally flashed) with your app:

spiffs_create_partition_image(<partition> <base_dir> [FLASH_IN_PROJECT] [DEPENDS dep dep ...])

Use the partition name from your partition table; image size is taken from the table. With FLASH_IN_PROJECT, idf.py flash will flash the SPIFFS image together with the app. The storage/spiffsgen example demonstrates this workflow.

Other tools: mkspiffs can create and unpack SPIFFS images; use it when you need to unpack an image or when Python is not available. There is no built-in ESP-IDF build integration for mkspiffs. The SPIFFS documentation describes when to prefer SPIFFSgen vs mkspiffs.

Whether files are created at runtime or embedded with SPIFFSgen, you use the same VFS file API (fopen, fread, etc.) to read and write them.

Conclusion

#

The SPIFFS component gives you a simple, partition-based filesystem for SPI NOR flash, with wear levelling and optional consistency checks. By registering SPIFFS with the VFS layer, you use standard C and POSIX file APIs for all read/write operations. The example shows the minimal mount–write–read flow; the discussion above outlines the options it uses and alternatives (partition_label/base_path, integrity check, SPIFFSgen for embedded files) so you can adapt SPIFFS to your project.
