ESP-WHO: Get started

Introduction

#

ESP-WHO is an image processing development platform built on Espressif chips. It provides a practical framework for developing computer vision applications, including human face detection, face recognition, pedestrian detection, and QR code recognition.

ESP-WHO enables developers to run image processing workloads directly on Espressif SoCs. The platform builds on the ESP-DL library or optimized deep learning inference and integrates with common peripherals such as cameras, displays, and storage. The current version targets the ESP32-S3 and the newer ESP32-P4 chips.

The framework uses a task-based architecture built on FreeRTOS. The base classes WhoTaskBase and WhoTask define a consistent lifecycle for asynchronous operations across the framework.

Component Hierarchy

#

ESP-WHO organizes functionality into components. The frame capture pipeline lives in who_frame_cap, where WhoFrameCapNode serves as the base class for processing stages. Nodes connect through queues and event bits to form an asynchronous pipeline.

For detection and recognition, WhoDetect consumes frames from a WhoFrameCapNode and runs an ESP-DL detection model (for example, face or pedestrian detection). WhoRecognitionCore extends detection by performing feature extraction and matching, and it manages an internal state machine for ENROLL, RECOGNIZE, and DELETE operations.

A typical workflow looks like this:

graph LR
    A[Camera Input] --> B[Frame Capture]
    B --> E[Detection]
    E --> C["Recognition
(Optional)"]
    C --> D["Output
(LCD / Terminal)"]
    E -.->|"Skip"| D

ESP-WHO follows a layered architecture with ESP-IDF at its foundation. It uses Board Support Packages (BSP) to abstract hardware differences, so the same application code can run on different targets such as the ESP32-S3-EYE or the ESP32-P4-Function-EV-Board. Applications select the right hardware drivers at compile time through configuration files like sdkconfig.bsp.<board_name>.

The examples currently support these evaluation boards:

• ESP32-P4 Function EV Board
• ESP32-S3-EYE
• ESP32-S3-Korvo-2

In this tutorial, we use the ESP32-S3-EYE board. We start by compiling and running the face recognition example, then extend it to turn on an LED whenever a face is detected.

Get started

#

In this section, we compile and run a face recognition example on the ESP32-S3-EYE board. This board includes both a camera and a display, so you can see detections in real time. A block diagram overview of its operation is shown below:

sequenceDiagram
    participant Camera
    participant WhoFrameCap
    participant WhoDetectBase
    participant WhoRecognition
    participant Display

    Camera->>WhoFrameCap: Raw frame
    WhoFrameCap->>WhoDetectBase: Processed frame
    Note over WhoDetectBase: Runs detection model
    WhoDetectBase->>WhoRecognition: Detection results
    WhoDetectBase->>Display: Detection results
    Note over WhoRecognition: Runs recognition model
    WhoRecognition->>Display: Recognition results

The example also includes facial feature management (saving and deleting) through button presses.

Prerequisites

#

ESP-WHO currently targets ESP-IDF v5.5.x. Before you begin, make sure you have this version installed.

Install ESP-IDF v5.5.x

#

• Open EIM, or install it if you do not have it on your machine.
• Choose Custom installation (the Quick installation defaults to ESP-IDF v6).
• Select and install ESP-IDF v5.5.x (at the time of writing, 5.5.4).

• Finish the installation procedure

Compile and run the example

#

1. Clone the esp-who repository:

   git clone https://github.com/espressif/esp-who.git


2. Open the esp-who/examples/human-face-recognition folder

To run esp-who you need to setup a couple of CMake flags. Here you can find the instructions for both VSCode and CLI.

During startup, you should see log messages showing the camera, buttons, and LVGL graphics stack initializing:

I (1240) cam_hal: cam init ok
I (1254) camera: Camera PID=0x26 VER=0x42 MIDL=0x7f MIDH=0xa2
I (1254) camera: Detected OV2640 camera
I (1254) camera: Detected camera at address=0x30
[...]
I (1732) LVGL: Starting LVGL task
I (1853) S3-EYE: Setting LCD backlight: 100%
[...]
W (1966) dl::Model: Minimize() will delete variables not used in model inference, which will make it impossible to test or debug the model.
[...]
I (2053) button: IoT Button Version: 4.1.5
I (2057) gpio: GPIO[0]| InputEn: 1| OutputEn: 0| OpenDrain: 0| Pullup: 1| Pulldown: 0| Intr:0
I (2065) main_task: Returned from app_main()

If everything works, you should now see the camera output on the LCD screen. Point the camera at your face and you should see dots marking your facial features.

Application Overview

#

This example follows the structure shown below.

flowchart TD
    subgraph Application Layer
        AppMain["app_main"]
        RecognitionApp["WhoRecognitionAppLCD"]
    end

    subgraph "Task Layer (who::recognition)"
        WhoRecognition["WhoRecognition"]
        WhoDetect["WhoDetect (Task)"]
        WhoRecognitionCore["WhoRecognitionCore (Task)"]
    end

    subgraph "Core Logic"
        HumanFaceRecognizer["HumanFaceRecognizer (ESP-DL)"]
    end

    subgraph "Storage Backends"
        FATFS["FATFS (Flash/SD Card)"]
        SPIFFS["SPIFFS"]
    end

    AppMain --> RecognitionApp
    RecognitionApp --> WhoRecognition
    WhoRecognition --> WhoDetect
    WhoRecognition --> WhoRecognitionCore
    WhoRecognitionCore --> HumanFaceRecognizer
    HumanFaceRecognizer --> FATFS
    HumanFaceRecognizer --> SPIFFS

WhoRecognitionAppLCD manages the camera frames, runs detection, stores recognition features on the SD card or flash, and renders the results on the display using LVGL.

In the next section, we extend the example to perform a custom action (logging a message and turning on an LED) whenever a face is detected.

Adding actions on detection

#

The example we just ran uses the WhoRecognitionAppLCD class. This class handles camera frames, runs detection, draws bounding boxes around detected faces, and lets you enroll, recognize, or delete face features through the display.

In this section, we add an action on detection: we log the detection to the console and turn on an LED.

To add custom behavior on detection, we create a subclass of WhoRecognitionAppLCD and override the detect_result_cb callback.

The detection result arrives in the result_t result parameter. We can use its det_res.empty() method to check whether any face was found.

Here is the code, followed by a step-by-step explanation:

class WhoRecognitionAppLCDWithCallback : public WhoRecognitionAppLCD {
public:
    WhoRecognitionAppLCDWithCallback(who::frame_cap::WhoFrameCap *frame_cap) : WhoRecognitionAppLCD(frame_cap)
    {
    }

protected:
    virtual void detect_result_cb(const who::detect::WhoDetect::result_t &result) override
    {
        // Log face detection to terminal
        if (!result.det_res.empty()) {
            ESP_LOGI("DETECTION", "Face detected!");
        }
        // Call parent implementation to keep LCD display working
        WhoRecognitionAppLCD::detect_result_cb(result);
    }
};

Class declaration and inheritance

#

class WhoRecognitionAppLCDWithCallback : public WhoRecognitionAppLCD {

We create a new class that inherits from WhoRecognitionAppLCD. Inheritance lets us keep all the existing behavior while adding our own.

Public constructor

#

public:
    WhoRecognitionAppLCDWithCallback(who::frame_cap::WhoFrameCap *frame_cap) : WhoRecognitionAppLCD(frame_cap)
    {
    }

• The initializer list : WhoRecognitionAppLCD(frame_cap) calls the parent constructor, which sets up the LCD, camera pipeline, and models.
• The empty body shows that we do not need any extra setup, since the parent already set everything up

Protected virtual method override

#

protected:
    virtual void detect_result_cb(const who::detect::WhoDetect::result_t &result) override
    {

• protected: keeps the method internal to the framework.
• virtual and override tell the compiler we are replacing the parent’s implementation.
• The framework calls this method automatically whenever detection runs.

Face detection check and logging

#

if (!result.det_res.empty()) {
    ESP_LOGI("DETECTION", "Face detected!");
}

We check whether det_res contains any results. If it does, we print a message to the terminal.

Call the parent implementation

#

WhoRecognitionAppLCD::detect_result_cb(result);

We forward the result to the parent so the LCD still draws bounding boxes and updates the UI. Without this call, the display would stop working.

#include "frame_cap_pipeline.hpp"
#include "who_recognition_app_lcd.hpp"
#include "who_recognition_app_term.hpp"
#include "who_spiflash_fatfs.hpp"

using namespace who::frame_cap;
using namespace who::app;
using namespace who::detect;

// Custom app class to inject the face detection callback
class WhoRecognitionAppLCDWithCallback : public WhoRecognitionAppLCD {
public:
    WhoRecognitionAppLCDWithCallback(who::frame_cap::WhoFrameCap *frame_cap) : WhoRecognitionAppLCD(frame_cap)
    {
    }

protected:
    virtual void detect_result_cb(const who::detect::WhoDetect::result_t &result) override
    {
        // Log face detection to terminal and turn on LED
        if (!result.det_res.empty()) {
            ESP_LOGI("DETECTION", "Face detected!");
            bsp_led_set(BSP_LED_GREEN, true);
        } else {
            bsp_led_set(BSP_LED_GREEN, false);
        }
        // Call parent implementation to keep LCD display working
        WhoRecognitionAppLCD::detect_result_cb(result);
    }
};

extern "C" void app_main(void)
{
    vTaskPrioritySet(xTaskGetCurrentTaskHandle(), 5);
    ESP_ERROR_CHECK(fatfs_flash_mount());
    ESP_ERROR_CHECK(bsp_leds_init());
    ESP_ERROR_CHECK(bsp_led_set(BSP_LED_GREEN, false));

    auto frame_cap = get_dvp_frame_cap_pipeline();

    auto recognition_app = new WhoRecognitionAppLCDWithCallback(frame_cap);
    // try this if you don't have a lcd.
    //auto recognition_app = new WhoRecognitionAppTerm(frame_cap);
    recognition_app->run();
}

If you now build and flash this firmware, the green LED turns on whenever a face is detected and turns off when no face is present.

Conclusion

#

In this article, we explored the ESP-WHO framework, compiled and ran a face recognition example on the ESP32-S3-EYE board, and learned how to extend the example with custom detection callbacks. We saw how ESP-WHO’s layered architecture, built on ESP-IDF and ESP-DL, makes it straightforward to add application-specific logic while preserving the framework’s display and recognition features.
