ESP-IDF tutorial series: Wi-Fi Provisioning

Introduction

#

IoT devices need an internet connection to perform their functions. When we manufacture an IoT device, we don’t know where it will end up, and we certainly won’t know the SSID and password of the end user’s network. For this reason, we always need a way for the customer to provide at least these two parameters.

The process of configuring, registering, and preparing a device so that it can securely and effectively connect to an IoT platform or cloud service is called provisioning.

Provisioning seems like a simple affair on the surface, but there are quite a few things to take care of. The majority of IoT devices lack input peripherals like keyboards or screens, so Wi-Fi and BLE are commonly used to provide communication. In this tutorial, we focus on Wi-Fi provisioning, where the main idea is to run an HTTP server on the device and let the user input the SSID and password via a smartphone browser or app.

The steps for the simplest possible Wi-Fi provisioning are at least:

1. The IoT device starts an Access Point (AP) and a Station (STA) interface (for later connection).
2. The IoT device starts an HTTP server.
3. The IoT device serves a page (or endpoint) with fields for SSID and password.
4. The user’s smartphone connects to the IoT device AP.
5. The user inputs the SSID and password.
6. The IoT device’s STA interface tries to connect to the target network.
7. On success, it reports a success message and shuts down the HTTP server.
8. On failure, it reports an error message.

Beyond this basic flow, we typically want:

• Visible SSID list: allow selecting an SSID instead of typing it manually.
• Security: avoid running an open AP because nearby parties could eavesdrop on traffic (including SSID and password).
• Authorization (proof of possession): prevent unauthorized parties from provisioning the device with their own credentials by enforcing a proof of possession (PoP).

We may also need to provide additional data to the device, such as a human-friendly device name or cloud certificates. It’s usually easier to handle these via a dedicated provisioning app rather than manual HTML forms.

To address these needs, Espressif provides the network_provisioning component, which is built on the transport-agnostic secure communication framework protocomm and includes the accompanying app ESP SoftAP Prov (Android, iOS) for provisioning.

The network_provisioning component

#

The network_provisioning component provides a complete system for configuring Wi-Fi and Thread network credentials on ESP devices. It handles smartphone to IoT device setup (SoftAP or BLE), secure credentials exchange, and automatic cleanup after a successful connection, so we don’t have to wire all of this together ourselves.

Security levels

#

The component supports three security levels:

Security Level 1 provides a good middle ground: it encrypts the communication channel using X25519 key exchange and AES-CTR, and authenticates the client through a pre-shared proof of possession string. Security Level 2 offers stronger authentication via SRP6a and is recommended for production.

In this tutorial, we use Security Level 1 to keep things straightforward while still having encryption and PoP.

With this background in place, let’s build a working example.

Getting started

#

In this tutorial, we perform Wi-Fi AP-based provisioning: the device waits for credentials, connects to the target network, and then prints “Hello World” in a loop.

Create a new project

#

1. Open VS Code.
2. In the command palette, type: > ESP-IDF: Create New Empty Project.
3. Name the project provisioning-tutorial.

Import dependencies

#

The first thing to do is import the network_provisioning component. This component is not part of the core ESP-IDF and is hosted in the ESP Component Registry. We can include registry components using the idf.py add-dependency command.

To find the command, we nee to search the network-provisioning component in the ESP Component Registry. The component page shows the required command.

1. Open an ESP-IDF Terminal: > ESP-IDF: Open ESP-IDF Terminal.
2. Run: idf.py add-dependency "espressif/network_provisioning^1.2.4".

An idf_component.yml file should now appear in our main folder:

.
├── CMakeLists.txt
├── main
│   ├── CMakeLists.txt
│   ├── idf_component.yml
│   └── main.c
├── sdkconfig
└── sdkconfig.old

The idf_component.yml content is:

## IDF Component Manager Manifest File
dependencies:
  ## Required IDF version
  idf:
    version: '>=4.1.0'
  # # Put list of dependencies here
  # # For components maintained by Espressif:
  # component: "~1.0.0"
  # # For 3rd party components:
  # username/component: ">=1.0.0,<2.0.0"
  # username2/component2:
  #   version: "~1.0.0"
  #   # For transient dependencies `public` flag can be set.
  #   # `public` flag doesn't have an effect dependencies of the `main` component.
  #   # All dependencies of `main` are public by default.
  #   public: true
  espressif/network_provisioning: ^1.2.4

Laying the groundwork

#

For provisioning, we need several subsystems initialized:

• Non-volatile storage (NVS) for persisting credentials across reboots.
• Network interface (esp_netif) for managing network interfaces.
• Event loop for responding to events generated by the IP stack, the Wi-Fi stack (connection/disconnection events), and the network_provisioning module itself.
• Wi-Fi access point and station, used during provisioning.
• Event group, used to make the main task wait until provisioning is complete

In the app_main function, add the initialization code along with the required includes:

#include <esp_log.h>
#include <esp_wifi.h>
#include <esp_event.h>
#include <nvs_flash.h>
#include <network_provisioning/manager.h>
#include <network_provisioning/scheme_softap.h>

static const char *TAG = "app";

const int WIFI_CONNECTED_EVENT = BIT0;
static EventGroupHandle_t wifi_event_group;

void app_main(void)
{
    ESP_ERROR_CHECK(nvs_flash_init());

    ESP_ERROR_CHECK(esp_netif_init());
    ESP_ERROR_CHECK(esp_event_loop_create_default());

    esp_netif_create_default_wifi_sta();
    esp_netif_create_default_wifi_ap();

    wifi_init_config_t cfg = WIFI_INIT_CONFIG_DEFAULT();
    ESP_ERROR_CHECK(esp_wifi_init(&cfg));
}

We also need to register event handler functions with the event loop. Let’s look at those next.

Event handlers

#

Event handlers are functions called when an event is triggered. In this example we will manage

• Wi-Fi events
• IP events
• Network provisioning event (i.e. triggered by the network_provisioning component).

Wi-Fi events

#

Wi-Fi events are grouped under the event base WIFI_EVENT. We want to:

• Log when a smartphone connects to or disconnects from the AP (WIFI_EVENT_AP_STACONNECTED and WIFI_EVENT_AP_STADISCONNECTED).
• Start the Wi-Fi connection when the STA interface starts or when it disconnects (WIFI_EVENT_STA_START and WIFI_EVENT_STA_DISCONNECTED).

static void wifi_event_handler(void *arg, esp_event_base_t event_base,
                               int32_t event_id, void *event_data)
{
    switch (event_id) {
    case WIFI_EVENT_AP_STACONNECTED:
        ESP_LOGI(TAG, "SoftAP transport: Connected!");
        break;
    case WIFI_EVENT_AP_STADISCONNECTED:
        ESP_LOGI(TAG, "SoftAP transport: Disconnected!");
        break;
    case WIFI_EVENT_STA_START:
        esp_wifi_connect();
        break;
    case WIFI_EVENT_STA_DISCONNECTED:
        ESP_LOGI(TAG, "Disconnected. Connecting to the AP again...");
        esp_wifi_connect();
        break;

    default:
        break;
    }
}

IP events

#

IP events are grouped under the event base IP_EVENT. When we get the IP from the router (IP_EVENT_STA_GOT_IP), it means that provisioning was successful. We want to:

• Stop the blocking of the main loop
• Log the IP address for debugging purposes

static void ip_event_handler(void *arg, esp_event_base_t event_base,
                             int32_t event_id, void *event_data)
{
    if (event_id == IP_EVENT_STA_GOT_IP) {
        ip_event_got_ip_t *event = (ip_event_got_ip_t *) event_data;
        ESP_LOGI(TAG, "Connected with IP Address:" IPSTR, IP2STR(&event->ip_info.ip));
        xEventGroupSetBits(wifi_event_group, WIFI_CONNECTED_EVENT);
    }
}

Network provisioning events

#

The network_provisioning component generates events through the ESP-IDF event system using the NETWORK_PROV_EVENT event base.

For this tutorial, we want to:

• Log when provisioning starts and free resources when it ends (NETWORK_PROV_START, NETWORK_PROV_END)
• Log Wi-Fi credentials when received (NETWORK_PROV_WIFI_CRED_RECV)
• Log if the credentials are correct or incorrect (NETWORK_PROV_WIFI_CRED_SUCCESS, NETWORK_PROV_WIFI_CRED_FAIL)

static void network_prov_event_handler(void *arg, esp_event_base_t event_base,
                                       int32_t event_id, void *event_data)
{
    switch (event_id) {
    case NETWORK_PROV_START:
        ESP_LOGI(TAG, "Provisioning started");
        break;
    case NETWORK_PROV_WIFI_CRED_RECV: {
        wifi_sta_config_t *wifi_sta_cfg = (wifi_sta_config_t *)event_data;
        ESP_LOGI(TAG, "Received Wi-Fi credentials"
                 "\n\tSSID     : %s\n\tPassword : %s",
                 (const char *) wifi_sta_cfg->ssid,
                 (const char *) wifi_sta_cfg->password);
        break;
    }
    case NETWORK_PROV_WIFI_CRED_FAIL: {
        network_prov_wifi_sta_fail_reason_t *reason = (network_prov_wifi_sta_fail_reason_t *)event_data;
        ESP_LOGE(TAG, "Provisioning failed!\n\tReason : %s"
                 "\n\tPlease reset to factory and retry provisioning",
                 (*reason == NETWORK_PROV_WIFI_STA_AUTH_ERROR) ?
                 "Wi-Fi station authentication failed" : "Wi-Fi access-point not found");
        break;
    }
    case NETWORK_PROV_WIFI_CRED_SUCCESS:
        ESP_LOGI(TAG, "Provisioning successful");
        break;
    case NETWORK_PROV_END: {
        esp_err_t err = network_prov_mgr_deinit();
        if (err != ESP_OK) {
            ESP_LOGE(TAG, "Failed to de-initialize provisioning manager: %s", esp_err_to_name(err));
        }
        break;
    }
    default:
        break;
    }
}

Handlers registration

#

Now register all three handlers right after creating the default event loop:

    ESP_ERROR_CHECK(esp_event_handler_register(WIFI_EVENT, ESP_EVENT_ANY_ID, &wifi_event_handler, NULL));
    ESP_ERROR_CHECK(esp_event_handler_register(IP_EVENT, IP_EVENT_STA_GOT_IP, &ip_event_handler, NULL));
    ESP_ERROR_CHECK(esp_event_handler_register(NETWORK_PROV_EVENT, ESP_EVENT_ANY_ID, &network_prov_event_handler, NULL));

Configuring network provisioning

#

The next step is to configure the network provisioning module to use SoftAP mode (as opposed to BLE) and initialize it:

    network_prov_mgr_config_t config = {
        .scheme = network_prov_scheme_softap,
        .scheme_event_handler = NETWORK_PROV_EVENT_HANDLER_NONE
    };

    ESP_ERROR_CHECK(network_prov_mgr_init(config));

Now we log the start of provisioning, define the security level and the proof of possession, and start the network provisioning manager itself:

    ESP_LOGI(TAG, "Starting provisioning");

    /* Security 1 */
    network_prov_security_t security = NETWORK_PROV_SECURITY_1;
    network_prov_security1_params_t *sec_params = PROOF_OF_POSSESSION;

    ESP_ERROR_CHECK(network_prov_mgr_start_provisioning(security, sec_params, AP_NAME, NULL));

After that, we print a link that generates a QR code for the provisioning app:

printf("Copy paste the below URL in a browser.\n%s?data={\"ver\":\"%s\",\"name\":\"%s\",\"PoP\":\"%s\",\"transport\":\"%s\"}\n",
           QRCODE_BASE_URL, PROV_QR_VERSION, AP_NAME, PROOF_OF_POSSESSION, PROV_TRANSPORT_SOFTAP);

Main loop

#

Now we need to wait for provisioning to complete (i.e., for the device to obtain an IP address) and then start the main loop:

xEventGroupWaitBits(wifi_event_group, WIFI_CONNECTED_EVENT, true, true, portMAX_DELAY);
 while (1) {
        ESP_LOGI(TAG, "Hello World!");
        vTaskDelay(1000 / portTICK_PERIOD_MS);
    }

#include <stdio.h>
#include <string.h>
#include <freertos/FreeRTOS.h>
#include <freertos/task.h>
#include <freertos/event_groups.h>
#include <esp_log.h>
#include <esp_wifi.h>
#include <esp_event.h>
#include <nvs_flash.h>

#include <network_provisioning/manager.h>
#include <network_provisioning/scheme_softap.h>

static const char *TAG = "app";

const int WIFI_CONNECTED_EVENT = BIT0;
static EventGroupHandle_t wifi_event_group;

const char *pop = "abcd1234";

#define PROV_QR_VERSION         "v1"
#define PROV_TRANSPORT_SOFTAP   "softap"
#define QRCODE_BASE_URL         "https://espressif.github.io/esp-jumpstart/qrcode.html"
#define AP_NAME "PROV_TestProvisioning"


static void network_prov_event_handler(void *arg, esp_event_base_t event_base,
                                       int32_t event_id, void *event_data)
{
    switch (event_id) {
    case NETWORK_PROV_START:
        ESP_LOGI(TAG, "Provisioning started");
        break;
    case NETWORK_PROV_WIFI_CRED_RECV: {
        wifi_sta_config_t *wifi_sta_cfg = (wifi_sta_config_t *)event_data;
        ESP_LOGI(TAG, "Received Wi-Fi credentials"
                 "\n\tSSID     : %s\n\tPassword : %s",
                 (const char *) wifi_sta_cfg->ssid,
                 (const char *) wifi_sta_cfg->password);
        break;
    }
    case NETWORK_PROV_WIFI_CRED_FAIL: {
        network_prov_wifi_sta_fail_reason_t *reason = (network_prov_wifi_sta_fail_reason_t *)event_data;
        ESP_LOGE(TAG, "Provisioning failed!\n\tReason : %s"
                 "\n\tPlease reset to factory and retry provisioning",
                 (*reason == NETWORK_PROV_WIFI_STA_AUTH_ERROR) ?
                 "Wi-Fi station authentication failed" : "Wi-Fi access-point not found");
        break;
    }
    case NETWORK_PROV_WIFI_CRED_SUCCESS:
        ESP_LOGI(TAG, "Provisioning successful");
        break;
    case NETWORK_PROV_END: {
        esp_err_t err = network_prov_mgr_deinit();
        if (err != ESP_OK) {
            ESP_LOGE(TAG, "Failed to de-initialize provisioning manager: %s", esp_err_to_name(err));
        }
        break;
    }
    default:
        break;
    }
}

static void wifi_event_handler(void *arg, esp_event_base_t event_base,
                               int32_t event_id, void *event_data)
{
    switch (event_id) {
    case WIFI_EVENT_STA_START:
        esp_wifi_connect();
        break;
    case WIFI_EVENT_STA_DISCONNECTED:
        ESP_LOGI(TAG, "Disconnected. Connecting to the AP again...");
        esp_wifi_connect();
        break;
    case WIFI_EVENT_AP_STACONNECTED:
        ESP_LOGI(TAG, "SoftAP transport: Connected!");
        break;
    case WIFI_EVENT_AP_STADISCONNECTED:
        ESP_LOGI(TAG, "SoftAP transport: Disconnected!");
        break;
    default:
        break;
    }
}

static void ip_event_handler(void *arg, esp_event_base_t event_base,
                             int32_t event_id, void *event_data)
{
    if (event_id == IP_EVENT_STA_GOT_IP) {
        ip_event_got_ip_t *event = (ip_event_got_ip_t *) event_data;
        ESP_LOGI(TAG, "Connected with IP Address:" IPSTR, IP2STR(&event->ip_info.ip));
        xEventGroupSetBits(wifi_event_group, WIFI_CONNECTED_EVENT);
    }
}

void app_main(void)
{
    /* Initialize NVS partition */
    ESP_ERROR_CHECK(nvs_flash_init());

    ESP_ERROR_CHECK(esp_netif_init());
    ESP_ERROR_CHECK(esp_event_loop_create_default());
    wifi_event_group = xEventGroupCreate();

    ESP_ERROR_CHECK(esp_event_handler_register(NETWORK_PROV_EVENT, ESP_EVENT_ANY_ID, &network_prov_event_handler, NULL));
    ESP_ERROR_CHECK(esp_event_handler_register(WIFI_EVENT, ESP_EVENT_ANY_ID, &wifi_event_handler, NULL));
    ESP_ERROR_CHECK(esp_event_handler_register(IP_EVENT, IP_EVENT_STA_GOT_IP, &ip_event_handler, NULL));

    esp_netif_create_default_wifi_sta();
    esp_netif_create_default_wifi_ap();

    wifi_init_config_t cfg = WIFI_INIT_CONFIG_DEFAULT();
    ESP_ERROR_CHECK(esp_wifi_init(&cfg));

    /* Configuration for the provisioning manager */
    network_prov_mgr_config_t config = {
        .scheme = network_prov_scheme_softap,
        .scheme_event_handler = NETWORK_PROV_EVENT_HANDLER_NONE
    };

    ESP_ERROR_CHECK(network_prov_mgr_init(config));


    ESP_LOGI(TAG, "Starting provisioning");

    /* Security 1 */
    network_prov_security_t security = NETWORK_PROV_SECURITY_1;
    network_prov_security1_params_t *sec_params = pop;

    ESP_ERROR_CHECK(network_prov_mgr_start_provisioning(security, sec_params, AP_NAME, NULL));

    printf("Copy paste the below URL in a browser.\n%s?data={\"ver\":\"%s\",\"name\":\"%s\",\"pop\":\"%s\",\"transport\":\"%s\"}\n",
           QRCODE_BASE_URL, PROV_QR_VERSION, AP_NAME, pop, PROV_TRANSPORT_SOFTAP);

    xEventGroupWaitBits(wifi_event_group, WIFI_CONNECTED_EVENT, true, true, portMAX_DELAY);

    while (1) {
        ESP_LOGI(TAG, "Hello World!");
        vTaskDelay(1000 / portTICK_PERIOD_MS);
    }
}

Testing the provisioning

#

To test provisioning, we flash the firmware to our device, install the provisioning app on our phone, and scan the QR code.

On the laptop

#

• In the VS Code command palette, type: > ESP-IDF: Build, Flash, and Start a Monitor on Your Device.

  We should see output similar to the following, with the device waiting for a client to connect:

  I (483) app: Starting provisioning
  I (493) phy_init: phy_version 1232,d493f299,Aug 25 2025,19:01:20
  I (533) wifi:mode : sta (7c:df:a1:42:64:70)
  I (533) wifi:enable tsf
  I (543) wifi:mode : sta (7c:df:a1:42:64:70) + softAP (7c:df:a1:42:64:71)
  I (543) wifi:Total power save buffer number: 16
  I (543) wifi:Init max length of beacon: 752/752
  I (543) wifi:Init max length of beacon: 752/752
  I (553) esp_netif_lwip: DHCP server started on interface WIFI_AP_DEF with IP: 192.168.4.1
  I (553) wifi:Total power save buffer number: 16
  I (563) esp_netif_lwip: DHCP server started on interface WIFI_AP_DEF with IP: 192.168.4.1
  I (573) network_prov_mgr: Provisioning started with service name : PROV_TestProvisioning
  I (573) app: Provisioning started
  Copy paste the below URL in a browser.
  https://espressif.github.io/esp-jumpstart/qrcode.html?data={"ver":"v1","name":"PROV_TestProvisioning","pop":"abcd1234","transport":"softap"}


• Copy the link from the terminal output and paste it into our laptop’s browser address bar. We should see a QR code like the one in the following picture:

On the smartphone

#

• Download the ESP SoftAP Prov app for your smartphone:

  • Android
  • iOS

• Open the ESP SoftAP Prov app.

• Tap Provision New Device.

• Use the camera to scan the QR code displayed in the browser.



• Choose your router’s SSID from the list.



• Enter the password for your router.

• We should now see the success screen.



Our device is now provisioned!

Skipping provisioning on subsequent boots

#

With the code above, every time we restart the device, provisioning runs again from scratch. To avoid this, we can check whether Wi-Fi credentials are already stored in NVS before starting the provisioning flow:

bool provisioned = false;
ESP_ERROR_CHECK(network_prov_mgr_is_wifi_provisioned(&provisioned));

If provisioned is true, we can skip the provisioning step entirely and connect directly.

The full code is available in the developer-portal-codebase repository, and you can find additional examples in the idf-extra-components repo.

Under the hood

#

Now that we have a working provisioning example, below you can find some detail about how network_provisioning and protocomm work together.

network_provisioning: how it works

#

protocomm: the communication layer

#

Security Level 1 deep dive

#

Conclusion

#

This article covered practical Wi‑Fi provisioning for IoT devices using Espressif’s network_provisioning and the protocomm transport. We implemented a SoftAP-based example (Security Level 1), handled Wi‑Fi and provisioning events, tested the flow with the ESP SoftAP Prov app, and showed how to skip provisioning on subsequent boots by checking NVS. We also examined the internals of network_provisioning/protocomm so you can understand how transport, security, and sessions are managed.

The example provides a solid foundation for integrating secure provisioning into devices. For production, consider stronger authentication (Security Level 2), robust PoP management, and protecting device identity and credentials.
