Part 2: Implement the Driver Functions

Table of Contents

Understand the generated app_devices.c scaffold and fill in the three driver sections: LED strip initialisation, BOOT button handling, and the FreeRTOS rainbow cycling task.

WSRMS - This article is part of a series.

Part 1: Part 1: Build Your Data Model in Studio

Part 2: This Article

Part 3: Part 3: Build, Flash, and Test

In this part, you will implement the hardware driver in app_devices.c. The driver will initialise the onboard WS2812 LED strip, handle BOOT button presses, and fill in the write callback so cloud and app controls drive the rainbow effect on the device.

After downloading the project in Part 1, your folder layout should look like this:

rainbow_led/
├── CMakeLists.txt                ← ESP-IDF project build file
├── partitions.csv                ← flash partition table
├── partitions_4mb_optimised.csv  ← optimised partition table for 4 MB flash
├── sdkconfig.defaults            ← default SDK configuration
├── sdkconfig.defaults.esp32c3    ← ESP32-C3-specific defaults
└── main/
    ├── CMakeLists.txt            ← main component build file
    ├── app_main.c                ← fully generated; do not modify
    ├── app_devices.c             ← generated scaffold; add your driver here
    ├── app_devices.h             ← device and driver declarations
    └── idf_component.yml         ← component manager dependencies

app_main.c is complete as-is. It initialises RainMaker, NVS, network, OTA, timezone, scheduling, scenes, system service, and Insights in the correct order. You never need to touch it.

Only two files need changes in this part:

File	Purpose
`main/app_devices.c`	All driver work goes here
`main/idf_component.yml`	Add hardware component dependencies

No other files need changes.

Understanding the Generated Code in app_devices.c
#

Studio translates the Rainbow LED data model from Part 1 into RainMaker C code. The generated project is already structured around your node, device, parameters, and services.

At the top, #define constants name the node, device, and each parameter with the matching RainMaker types from your Studio model:

#define NODE_NAME                           "Node"
#define NODE_TYPE                           "rainbowled"

#define RAINBOW_LED_DEVICE_NAME             "RainBow LED"
#define RAINBOW_LED_DEVICE_TYPE             "esp.device.rainbow"

#define RAINBOW_LED_POWER_PARAM_NAME        "Power"
#define RAINBOW_LED_BRIGHTNESS_PARAM_NAME   "Brightness"
#define RAINBOW_LED_CYCLE_SPEED_PARAM_NAME  "Cycle Speed"

The generated functions fall into two groups:

Already implemented

Function	What it does
`app_device_create_node()`	Initialises the RainMaker node with your model and type
`app_device_create()`	Creates the Rainbow LED device, registers `app_device_bulk_write_cb()`, and adds Power, Brightness, and Cycle Speed with the correct param types, default values, and bounds from Studio (including the Cycle Speed slider, min 1, max 10, default 5)
`app_device_bulk_write_cb()`	Receives parameter updates from the cloud or phone app, routes them by device and parameter name, and calls `esp_rmaker_param_update()`

Left for you to implement

Section	What to do
`app_driver_init()`	Initialise the WS2812 LED strip, BOOT button, and runtime state
`app_device_bulk_write_cb()` (`if/else` branches)	Scaffolded but marked `TODO`; apply incoming Power, Brightness, and Cycle Speed values to hardware
`app_device_set_mfg_data()`	Set manufacturing data for provisioning (optional for this workshop)

Now that you know what Studio has generated, which files need to be edited, and what remains to be implemented, let’s proceed with the following steps:

Add the hardware component dependencies with idf.py add-dependency
Implement app_driver_init() to initialise the WS2812 LED strip, BOOT button, and rainbow task
Fill in app_device_bulk_write_cb() so Power, Brightness, and Cycle Speed updates from the app reach the hardware

Add Component Dependencies
#

The hardware driver needs two ESP-IDF components on top of what Studio already included in main/idf_component.yml. From your project root, run:

idf.py add-dependency "espressif/led_strip^2.0.0"
idf.py add-dependency "espressif/button^3.0.0"

The Component Manager fetches these automatically on the first idf.py build.

Alternatively, you can also add these entries to main/idf_component.yml manually:

  espressif/led_strip:
    version: ">=2.0.0"
  espressif/button:
    version: ">=3.0.0"

Implement app_driver_init()
#

The ESP32-C3-DevKitC has:

WS2812 RGB LED on GPIO 8 (driven via RMT)
BOOT button on GPIO 9 (active low)

Add these constants near the top of app_devices.c:

/* ESP32-C3-DevKitC hardware */
#define LED_STRIP_GPIO      8
#define LED_STRIP_MAX_LEDS  1
#define BUTTON_GPIO         9
#define BUTTON_ACTIVE_LEVEL 0

app_driver_init() does three things:

1. Initialise the WS2812 LED strip:

led_strip_config_t strip_cfg = {
    .strip_gpio_num   = LED_STRIP_GPIO,
    .max_leds         = LED_STRIP_MAX_LEDS,
    .led_pixel_format = LED_PIXEL_FORMAT_GRB,
    .led_model        = LED_MODEL_WS2812,
};
led_strip_rmt_config_t rmt_cfg = {
    .clk_src       = RMT_CLK_SRC_DEFAULT,
    .resolution_hz = 10 * 1000 * 1000,
};
ESP_ERROR_CHECK(led_strip_new_rmt_device(&strip_cfg, &rmt_cfg, &s_led_strip));
led_strip_clear(s_led_strip);

2. Initialise the BOOT button with callbacks:

button_config_t btn_cfg = {
    .type             = BUTTON_TYPE_GPIO,
    .long_press_time  = 1000,
    .short_press_time = 50,
    .gpio_button_config = {
        .gpio_num     = BUTTON_GPIO,
        .active_level = BUTTON_ACTIVE_LEVEL,
    },
};
button_handle_t btn = iot_button_create(&btn_cfg);
iot_button_register_cb(btn, BUTTON_SINGLE_CLICK,     button_single_click_cb, NULL);
iot_button_register_cb(btn, BUTTON_LONG_PRESS_START, button_long_press_cb,   NULL);

3. Start the rainbow cycling FreeRTOS task:

xTaskCreate(rainbow_task, "rainbow", 4096, NULL, 5, NULL);

The rainbow_task runs every 50 ms, increments the HSV hue by the current speed value, converts to RGB, and writes to the LED strip:

static void rainbow_task(void *arg)
{
    while (1) {
        if (s_power) {
            s_hue += (float)s_speed;
            if (s_hue >= 360.0f) s_hue -= 360.0f;

            uint8_t r, g, b;
            hsv_to_rgb(s_hue, 1.0f, s_brightness / 100.0f, &r, &g, &b);
            led_strip_set_pixel(s_led_strip, 0, r, g, b);
            led_strip_refresh(s_led_strip);
        } else {
            led_strip_clear(s_led_strip);
            led_strip_refresh(s_led_strip);
        }
        vTaskDelay(pdMS_TO_TICKS(50));
    }
}

Button behaviour:

Button action	Effect
Single click	Toggles Power on/off and reports to RainMaker
Long press (1 s)	Randomises Speed and Brightness, reports to RainMaker

Any local hardware change is reported back to the cloud using esp_rmaker_param_update_and_report() so the phone app always stays in sync.

Fill in the Write Callback
#

Replace the three TODO branches in app_device_bulk_write_cb() to apply incoming values to the runtime state variables:

if (strcmp(param_name, RAINBOW_LED_POWER_PARAM_NAME) == 0) {
    s_power = val.val.b;
    ESP_LOGI(TAG, "Power: %s", s_power ? "ON" : "OFF");

} else if (strcmp(param_name, RAINBOW_LED_BRIGHTNESS_PARAM_NAME) == 0) {
    s_brightness = val.val.i;
    ESP_LOGI(TAG, "Brightness: %d", s_brightness);

} else if (strcmp(param_name, RAINBOW_LED_CYCLE_SPEED_PARAM_NAME) == 0) {
    s_speed = val.val.i;
    ESP_LOGI(TAG, "Cycle Speed: %d", s_speed);
}

The rainbow_task reads s_power, s_brightness, and s_speed directly, so changes take effect within the next 50 ms tick, with no additional signalling required.

Complete app_devices.c
#

The fully implemented file is available for reference below.

View full code

#include <math.h>
#include <string.h>
#include <esp_log.h>
#include <esp_random.h>
#include <esp_rmaker_core.h>
#include <esp_rmaker_standard_types.h>
#include <esp_rmaker_standard_devices.h>
#include <esp_rmaker_standard_params.h>
#include <app_network.h>
#include <freertos/FreeRTOS.h>
#include <freertos/task.h>
#include <led_strip.h>
#include <iot_button.h>
#include "app_devices.h"

#define NODE_NAME "Node"
#define NODE_TYPE "rainbowled"

#define RAINBOW_LED_DEVICE_NAME            "Rainbow LED"
#define RAINBOW_LED_DEVICE_TYPE            "esp.device.rainbow"
#define RAINBOW_LED_POWER_PARAM_NAME       "Power"
#define RAINBOW_LED_POWER_PARAM_TYPE       "esp.param.power"
#define RAINBOW_LED_BRIGHTNESS_PARAM_NAME  "Brightness"
#define RAINBOW_LED_BRIGHTNESS_PARAM_TYPE  "esp.param.brightness"
#define RAINBOW_LED_CYCLE_SPEED_PARAM_NAME "Cycle Speed"
#define RAINBOW_LED_CYCLE_SPEED_PARAM_TYPE "esp.param.cycle_speed"

/* ESP32-C3-DevKitC hardware */
#define LED_STRIP_GPIO      8
#define LED_STRIP_MAX_LEDS  1
#define BUTTON_GPIO         9
#define BUTTON_ACTIVE_LEVEL 0

static const char *TAG = "app_devices";

esp_rmaker_device_t *rainbow_led_device;
static led_strip_handle_t s_led_strip;

static volatile bool s_power      = true;
static volatile int  s_brightness = 30;
static volatile int  s_speed      = 5;
static float         s_hue        = 0.0f;

static void hsv_to_rgb(float h, float s, float v,
                       uint8_t *r, uint8_t *g, uint8_t *b)
{
    float c = v * s;
    float x = c * (1.0f - fabsf(fmodf(h / 60.0f, 2.0f) - 1.0f));
    float m = v - c;
    float r1, g1, b1;
    if      (h < 60)  { r1 = c; g1 = x; b1 = 0; }
    else if (h < 120) { r1 = x; g1 = c; b1 = 0; }
    else if (h < 180) { r1 = 0; g1 = c; b1 = x; }
    else if (h < 240) { r1 = 0; g1 = x; b1 = c; }
    else if (h < 300) { r1 = x; g1 = 0; b1 = c; }
    else              { r1 = c; g1 = 0; b1 = x; }
    *r = (uint8_t)((r1 + m) * 255.0f);
    *g = (uint8_t)((g1 + m) * 255.0f);
    *b = (uint8_t)((b1 + m) * 255.0f);
}

static void rainbow_task(void *arg)
{
    while (1) {
        if (s_power) {
            s_hue += (float)s_speed;
            if (s_hue >= 360.0f) s_hue -= 360.0f;
            uint8_t r, g, b;
            hsv_to_rgb(s_hue, 1.0f, s_brightness / 100.0f, &r, &g, &b);
            led_strip_set_pixel(s_led_strip, 0, r, g, b);
            led_strip_refresh(s_led_strip);
        } else {
            led_strip_clear(s_led_strip);
            led_strip_refresh(s_led_strip);
        }
        vTaskDelay(pdMS_TO_TICKS(50));
    }
}

static void report_param(const char *name, esp_rmaker_param_val_t val)
{
    if (!rainbow_led_device) return;
    esp_rmaker_param_t *p = esp_rmaker_device_get_param_by_name(rainbow_led_device, name);
    if (p) esp_rmaker_param_update_and_report(p, val);
}

static void button_single_click_cb(void *arg, void *usr_data)
{
    s_power = !s_power;
    ESP_LOGI(TAG, "Button: Power -> %s", s_power ? "ON" : "OFF");
    report_param(RAINBOW_LED_POWER_PARAM_NAME, esp_rmaker_bool(s_power));
}

static void button_long_press_cb(void *arg, void *usr_data)
{
    s_speed      = 1  + (esp_random() % 10);
    s_brightness = 10 + (esp_random() % 91);
    ESP_LOGI(TAG, "Button: Speed=%d Brightness=%d", s_speed, s_brightness);
    report_param(RAINBOW_LED_CYCLE_SPEED_PARAM_NAME, esp_rmaker_int(s_speed));
    report_param(RAINBOW_LED_BRIGHTNESS_PARAM_NAME,  esp_rmaker_int(s_brightness));
}

void app_driver_init(void)
{
    led_strip_config_t strip_cfg = {
        .strip_gpio_num   = LED_STRIP_GPIO,
        .max_leds         = LED_STRIP_MAX_LEDS,
        .led_pixel_format = LED_PIXEL_FORMAT_GRB,
        .led_model        = LED_MODEL_WS2812,
    };
    led_strip_rmt_config_t rmt_cfg = {
        .clk_src        = RMT_CLK_SRC_DEFAULT,
        .resolution_hz  = 10 * 1000 * 1000,
        .flags.with_dma = false,
    };
    ESP_ERROR_CHECK(led_strip_new_rmt_device(&strip_cfg, &rmt_cfg, &s_led_strip));
    led_strip_clear(s_led_strip);

    button_config_t btn_cfg = {
        .type             = BUTTON_TYPE_GPIO,
        .long_press_time  = 1000,
        .short_press_time = 50,
        .gpio_button_config = {
            .gpio_num     = BUTTON_GPIO,
            .active_level = BUTTON_ACTIVE_LEVEL,
        },
    };
    button_handle_t btn = iot_button_create(&btn_cfg);
    iot_button_register_cb(btn, BUTTON_SINGLE_CLICK,     button_single_click_cb, NULL);
    iot_button_register_cb(btn, BUTTON_LONG_PRESS_START, button_long_press_cb,   NULL);

    xTaskCreate(rainbow_task, "rainbow", 4096, NULL, 5, NULL);
}

esp_rmaker_node_t *app_device_create_node(esp_rmaker_config_t *config)
{
    esp_rmaker_node_t *node = esp_rmaker_node_init(config, NODE_NAME, NODE_TYPE);
    if (!node) {
        ESP_LOGE(TAG, "Could not initialise node. Aborting!!!");
        return NULL;
    }
    return node;
}

static esp_err_t app_device_bulk_write_cb(const esp_rmaker_device_t *device,
                                           const esp_rmaker_param_write_req_t write_req[],
                                           uint8_t count, void *priv_data,
                                           esp_rmaker_write_ctx_t *ctx)
{
    if (ctx) {
        ESP_LOGI(TAG, "Received write via: %s", esp_rmaker_device_cb_src_to_str(ctx->src));
    }
    for (int i = 0; i < count; i++) {
        const esp_rmaker_param_t *param = write_req[i].param;
        esp_rmaker_param_val_t    val   = write_req[i].val;
        const char *param_name = esp_rmaker_param_get_name(param);

        if (strcmp(param_name, RAINBOW_LED_POWER_PARAM_NAME) == 0) {
            s_power = val.val.b;
            ESP_LOGI(TAG, "Power: %s", s_power ? "ON" : "OFF");
        } else if (strcmp(param_name, RAINBOW_LED_BRIGHTNESS_PARAM_NAME) == 0) {
            s_brightness = val.val.i;
            ESP_LOGI(TAG, "Brightness: %d", s_brightness);
        } else if (strcmp(param_name, RAINBOW_LED_CYCLE_SPEED_PARAM_NAME) == 0) {
            s_speed = val.val.i;
            ESP_LOGI(TAG, "Cycle Speed: %d", s_speed);
        } else {
            ESP_LOGW(TAG, "Unknown param: %s", param_name);
        }
        esp_rmaker_param_update(param, val);
    }
    return ESP_OK;
}

esp_rmaker_device_t *app_device_create(esp_rmaker_node_t *node)
{
    rainbow_led_device = esp_rmaker_device_create(RAINBOW_LED_DEVICE_NAME,
                                                   RAINBOW_LED_DEVICE_TYPE, NULL);
    if (!rainbow_led_device) {
        ESP_LOGE(TAG, "Failed to create %s", RAINBOW_LED_DEVICE_NAME);
        return NULL;
    }
    esp_rmaker_device_add_bulk_cb(rainbow_led_device, app_device_bulk_write_cb, NULL);
    esp_rmaker_device_add_param(rainbow_led_device,
        esp_rmaker_power_param_create(RAINBOW_LED_POWER_PARAM_NAME, false));
    esp_rmaker_device_add_param(rainbow_led_device,
        esp_rmaker_brightness_param_create(RAINBOW_LED_BRIGHTNESS_PARAM_NAME, 30));
    esp_rmaker_param_t *speed_param = esp_rmaker_param_create(
        RAINBOW_LED_CYCLE_SPEED_PARAM_NAME, RAINBOW_LED_CYCLE_SPEED_PARAM_TYPE,
        esp_rmaker_int(5), PROP_FLAG_READ | PROP_FLAG_WRITE);
    esp_rmaker_param_add_ui_type(speed_param, ESP_RMAKER_UI_SLIDER);
    esp_rmaker_param_add_bounds(speed_param,
        esp_rmaker_int(1), esp_rmaker_int(10), esp_rmaker_int(1));
    esp_rmaker_device_add_param(rainbow_led_device, speed_param);
    esp_rmaker_node_add_device(node, rainbow_led_device);
    return rainbow_led_device;
}

esp_err_t app_device_set_mfg_data(void)
{
    return app_network_set_custom_mfg_data(MGF_DATA_DEVICE_TYPE_LIGHT,
                                           MFG_DATA_DEVICE_SUBTYPE_LIGHT);
}

Next Step
#

Next → Part 3: Build, Flash, and Test

Or go back to the workshop overview

WSRMS - This article is part of a series.

Part 1: Part 1: Build Your Data Model in Studio

Part 2: This Article

Part 3: Part 3: Build, Flash, and Test

Understanding the Generated Code in app_devices.c#

Add Component Dependencies#

Implement app_driver_init()#

Fill in the Write Callback#

Complete app_devices.c#

Next Step#

Related
